Metaldetector FM-3020

Metal foreign object detection systems for use in food processing, chemical manufacturing, pharmaceuticals, cosmetics, toy production, and various other industries. Applications include detecting metal parts in bagged snacks, meat products, frozen foods, plastic bottle beverages, toiletries, and more.

High Sensitivity and Stability:
- Achieves accuracy up to detecting ferrous materials (FE) as small as 1.0mm, non-ferrous materials (NON-FE) as small as 1.2mm, and SUS304 stainless steel as small as 1.5mm.
- Robust anti-interference capabilities to minimize false rejections and ensure reliable performance.

Customizable:
- The system is adaptable to various rejector systems, allowing for customization to suit specific operational requirements and integration with existing production setups.

User-Friendly Features:

Incorporates an auto-learning function, enabling effortless setup and calibration. Capable of storing settings for up to 100 different products.
Seamless integration with printers, labeling machines, and other peripheral equipment for enhanced efficiency and automation.
Data storage capacity extends up to 1 year, with the ability to export data in .xls format and save it to a USB flash disk, ensuring convenient access to vital information for analysis and record-keeping purposes.

Easy Maintenance:

The conveyor is designed for easy disassembly, simplifying maintenance procedures and minimizing downtime.
Constructed entirely from stainless steel 304, ensuring durability, resistance to corrosion, and ease of cleaning.
Incorporates a detachable belts design, facilitating straightforward cleaning and maintenance tasks, further enhancing operational efficiency and hygiene standards.

Model: FMD-3015

Specifications:
- Height: 150mm
- Width: 300mm
- Body Length (without rejector): 1500mm
- Transmission Speed: 30m/min
- Sensitivity (without product):
- Ferrous (FE): 1.0mm
- Non-Ferrous (NFE): 1.2mm
- SUS304: 1.5mm
- Operation Button
- Power Supply: AC220/110V±10% 50Hz/60Hz
- Alarm: Audible and visual alarm
- Rejector: Multi Rejector Selectable
- Waterproof Level: IP54/IP66
- Product Preset: High-Speed A/D Sampling Module
- Operating Requirement: Temperature: 0℃～40℃, Humidity: 30%～95%
- Main Structure: SUS304 Stainless Steel
